SPECIFICATIONS CS-3510
56 X7503360201
© 8/20 ECHO Incorporated
SPECIFICATIONS
* Technical data subject to change without notice.
Model CS-3510
Length 386 mm (15.2 in.)
Width 233 mm (9.2 in.)
Height 271 mm (10.7 in.)
Dry weight 3.7 kg (8.2 lb.) Without chain and guide bar
Engine Air-cooled two-stroke single cylinder
Displacement 34.4 mL (2.1 cu. in.)
Bore 40.0 mm (1.570 in.)
Stroke 27.4 mm (1.08 in.)
Compressions ratio 7.4:1
Carburetor Diaphragm type
Spark plug NGK BPMR8Y (Gap 0.65 mm [0.026 in.])
Fuel tank capacity 280 mL (9.47 US. fl. oz.)
Fuel 50:1
Gasoline Use 89 octane unleaded. Do not use fuel containing
methyl alcohol, more than 10% ethyl alcohol or 15%
MTBE. Do not use alternative fuels such as E-15 or E-
85.
Oil ISO-L-EGD (ISO/CD 13738) and JASO M345-FD
two-stroke, air-cooled engine oil.
Oiling system automatic oiler
Chain oil capacity 230 mL (7.78 US. fl. oz.)
Starter system Automatic rewind starter
Clutch Centrifugal type
Sprocket type Spur type, 6-tooth, 3/8 in. pitch
Chain brake Automatic band brake type
Idle speed 3,000 RPM
Clutch engagement speed 4,500 RPM
Wide open throttle speed
(W.O.T.)
13,300 RPM
Chain tensioner Side access system
Guide bar 14, 16 in
Saw chain 91PX
Standard features
Front hand guard, Rear hand guard, Anti-vibration
device, Throttle control lockout, Chain catcher, Spark
arrestor muffler
