Echo CS-3510 User Manual

OPERATION CS-3510
32 X7503360201
© 8/20 ECHO Incorporated
◆ After choke control knob is pulled and then knob is
returned to original position, throttle remains slightly open
(fast idle latch condition).
◆ The chain will attempt to move when engine is started with
fast idle throttle latch engaged.
◆ Do not start engine before chain brake is locked.
6. Securely hold the chain saw and pull starter handle several times until
first starting sound.
7. Push choke control knob (B) all the way IN (OPEN choke position).
8. Pull starter handle to start the
engine.
Note: Do not pull starter rope out to
the maximum possible
position.
Note: Do not allow recoil handle to
snap back against the
casing.
Note: If engine does not start after 5 pulls, repeat instructions.
◆ After starting the engine, immediately squeeze and then
release throttle trigger to release fast idle throttle latch,
otherwise severe brake damage may occur.
◆ Never use fast idle throttle latch for cutting.
◆ Use the fast idle throttle latch only in starting.
Note: Do not increase engine speed while chain brake is locked.
Severe brake damage will result.
Starting Warm Engine
Make sure the bar and chain are free from any obstruction when
starting the chain saw.

Echo CS-3510 Specifications

General

Engine Displacement	34.4 cc
Bar Length	16 in
Chain Pitch	3/8 in
Chain Gauge	0.050 in
Fuel Capacity	0.27 liters
Oil Capacity	0.2 liters
Fuel Tank Capacity	0.27 liters
Oil Tank Capacity	0.2 liters
