CS-352 SPECIFICATIONS
X7503275704 55
© 09/20 ECHO Incorporated
SPECIFICATIONS
* Technical data subject to change without notice.
Model CS-352
Length 396 mm (15.6 in.)
Width 232 mm (9.1 in.)
Height 273 mm (10.7 in.)
Dry weight 4.0 kg (8.8 lb.) Without chain and guide bar
Engine Air-cooled two-stroke single cylinder
Displacement 34.0 mL (2.075 cu. in.)
Bore 38.0 mm (1.500 in.)
Stroke 30.0 mm (1.180 in.)
Compressions ratio 6.8:1
Carburetor Diaphragm type
Spark plug NGK BPMR8Y (Gap 0.65 mm [0.026 in.])
Fuel tank capacity 250 mL (8.5 US. fl. oz.)
Fuel 50:1
Gasoline Use 89 octane unleaded. Do not use fuel containing
methyl alcohol, more than 10% ethyl alcohol or 15%
MTBE. Do not use alternative fuels such as E-15 or E-
85.
Oil ISO-L-EGD (ISO/CD 13738) and JASO M345-FD
two-stroke, air-cooled engine oil.
Oiling system automatic oiler
Chain oil capacity 260 mL (8.8 US. fl. oz.)
Starter system Automatic rewind starter
Clutch Centrifugal type
Sprocket type Spur type, 6-tooth, 3/8 in. pitch
Chain brake Automatic band brake type
Idle speed 3,000 RPM
Clutch engagement speed 4,300 RPM
Wide open throttle speed
(W.O.T.)
12,500 RPM
Chain tensioner Side access system
Guide bar 12, 14, 16 in
Saw chain 91PX/91VG
Standard features
Front hand guard, Rear hand guard, Anti-vibration
device, Throttle control lockout, Chain catcher, Spark
arrestor muffler, (Kick Guard
TM
Optional)
