59
GUIDE BAR MOUNTING SYSTEM
CS-370ES
CS-420ES
10 GUIDE BAR MOUNTING SYSTEM
(A) Inner sprocket guard plate
(B) Outer sprocket guard plate
(C) Tensioner screw
(D) Chain tensioner
(E) Bevel gear
(F) Bevel gear
(G) Collar
(H) Guide bar stud
(A)
(B)
(C)
(D)
(E)
(F)
(G)
(H)
