Echo CS-420ES Service Manual

14
IGNITION SYSTEM
CS-370ES
CS-420ES
3 IGNITION SYSTEM
(A) Flywheel
(B) Ignition coil
(C) Spark plug
(D) Spark plug cap coil
(E) Spark plug cap
(F) High tension lead
(G) Primary lead
(H) Ground lead
(I) Spacer
(J) Switch bracket
(K) Throttle rod
(L) Lead terminal
(M) Ignition switch
(N) Choke knob
(O) Choke grommet
(P) Purge bulb
(A)
(B)
(C) (D)
(F)
(E)
(G)
(H)
(K)
(I)
(L)
(M)
(N)
(O)
(J)
(P)

Echo CS-420ES Specifications

General

Saw Chain Gauge	0.050 inches
Fuel Capacity	0.41 liters
Weight	4.6 kg
Saw Chain Pitch	3/8 inches
Bar Length	16 inches
