DSRM-200 MAINTENANCE
X7508161200 19
© 3/2014 ECHO Inc.
MAINTENANCE
Moving parts can amputate fingers or cause severe injuries. Keep hands, clothing, and loose
objects away from all openings. Always remove battery and make sure all moving parts have come
to a complete stop before removing obstructions, clearing debris, or servicing unit. Allow unit to
cool before performing service. Wear gloves to protect hands from sharp edges and hot surfaces.
Your ECHO trimmer is designed to provide many hours of trouble-free service. Regular scheduled
maintenance will help your trimmer achieve that goal. If you are unsure or are not equipped with the
necessary tools, you may want to take your unit to your authorized ECHO servicing dealer for maintenance.
Gear Case Lubrication
1. Clean all loose debris from gear case.
2. Remove plug (A) and check level of grease.
3. Add grease if necessary. DO NOT over-fill.
Nylon Line Replacement
Wear Gloves or personal injury may result:
• Cutoff knife is sharp.
• Gearcase and surrounding area may be hot.
1. Cut one piece of line to recommended length.
.080” (2.0 mm) dia. – 20’ (6 m)
2. Align arrows on top of knob with openings in eyelets.
3. Insert one end of trimmer line into an eyelet, and push line
equal distance through trimmer head.
For more information
scan this QR code.
