MAINTENANCE DSRM-200
4. Hold trimmer head while turning knob clockwise to wind line
onto spool until about 5” (13 cm) of each line remains
exposed.
Trimmer head is now fully loaded and ready for operation.
When the wear indicators located at the bottom of the
Speed-Feed® head are worn smooth, or if holes appear,
replacement of the cover or the entire Speed-Feed® head is
required.
Battery Removal
1. Release throttle trigger and throttle trigger lockout and allow
trimmer head to stop.
2. Slide stop switch backward to “0” position.
3. Push battery latch release (C) to release battery latch.
4. Remove battery.
