PB-580H/T MAINTENANCE
X7505200705 33
© 12/2017 ECHO Inc.
ENGLISH
1. CLOSE choke (COLD START
[ ] position). This prevents
dirt from entering the carburetor
throat when the air filter is
removed. Brush accumulated
dirt from air cleaner area.
2. Remove air filter cover. Brush
dirt from inside cover.
3. Remove air filter and lightly
brush debris from filter.
Replace filter if it is damaged,
fuel soaked, very dirty, or the
rubber sealing edges are
deformed.
4. If filter can be reused, be
certain it:
• Fits tightly in the air filter cavity
• Is installed with the original
side out
5. Install air filter cover.
Fuel Filter
Level 1.
Fuel is VERY flammable. Use extreme care when mixing,
storing or handling, or serious personal injury may result.
1. Use a clean rag to remove
loose dirt from around fuel cap
and empty fuel tank.
2. Pull the fuel line and filter from
the tank.
3. Remove the filter from the line
and install the new filter.
Parts Required: Tune Up Kit.
