PB-580H/T SPECIFICATIONS
X7505200705 43
© 12/2017 ECHO Inc.
ENGLISH
7. Allow engine to cool. Remove the spark plug lead from the spark plug.
Remove the spark plug. Pour 7 cc (0.25 oz.) of fresh, clean, two-stroke
engine oil into the cylinder through the spark plug hole.
8. Pull the recoil starter handle 2-3 times to distribute the oil inside the
engine.
9. Observe the piston location through the spark plug hole. Pull the recoil
handle slowly until the piston reaches the top of its travel and leave it
there.
10. Install the spark plug. Connect the spark plug lead to the spark plug.
11. Remove blower pipe assembly from unit.
SPECIFICATIONS
This spark ignition system complies with the Canadian
standard ICES-002.
MODEL PB-580 H PB-580 T
Length (w/o pipes) 379 mm (14.92in.) 379 mm (14.92 in.)
Width (w/o pipes) 537 mm (21.14 in.) 478 mm (18.82 in.)
Height (w/o pipes) 459 mm (18.07 in.)
Weight (dry) (w/o pipes) 9.4 kg (20.7 lb.) 9.3 kg (20.5 lb.)
Engine Type
Air cooled, two-stroke, single cylinder gasoline
engine
Bore 46.0 mm (1.81 in.)
Stroke 35.0 mm (1.38 in.)
Displacement 58.2 cc (3.55 cu. in.)
Exhaust
Spark arrestor muffler or spark arrestor muffler
with catalyst
Carburetor Diaphragm w/purge pump
Ignition System
Flywheel magneto, capacitor discharge
ignition type
Spark Plug NGK BPMR8Y (Gap 0.65 mm [0.026 in.])
Fuel Mixed (Gasoline and Two-stroke Oil)
Fuel/Oil Ratio
50 : 1 Power Blend X
TM
or ECHO Red Armor
®
ISO-L-EGD (ISO/CD 13738) and J.A.S.O.
M345- FD
, two-stroke, air-cooled engine oil.
