POWER PRUNER
TM
OPERATOR'S MANUAL
21
1. Remove spark plug lead from spark plug.
2. Remove the five screws that retain the engine cover. Two at the top
of the recoil starter, two on either side of the front and one in the
muffler cover. Lift the cover from the engine and lay to the front of
the Power Pruner
TM
.
NOTE
The spark plug lead and grommet remain installed in the engine
cover.
3. Use the brush to remove dirt from cylinder fins.
4. Remove grass and leaves from the grid between the recoil starter
and fuel tank.
5. Assemble components in reverse order.
EXHAUST SYSTEM
Spark Arrestor Screen
Level 2.
Tools Required: Screwdriver, Soft metal brush, 3 mm hex wrench
Parts Required: Spark Arrestor Screen P/N 14586240630,
Gasket P/N 14586642031
