PAS-225VP OPERATION
© 12/2013 ECHO Inc.
X7722273906 17
Storage - Fuel storage laws vary by locality. Contact your local government for the laws affecting your area.
As a precaution, store fuel in an approved, airtight container. Store in a well-ventilated, unoccupied building,
away from sparks and flames.
Stored fuel ages. Do not mix more fuel than you expect to use in thirty (30) days, ninety (90) days when a
fuel stabilizer is added.
Stored two-stroke fuel may separate. ALWAYS shake fuel container thoroughly before each use.
Operation With Blades
Blade use DEMANDS specific Brush Cutter configuration. Operation without specified shield, barrier
bar or U-handle, and harness can result in serious personal injury. Follow installation instructions.
DO NOT INSTALL BLADES ON GT (CURVED SHAFT) MODEL TRIMMERS.
• Arbor Diameter of Upper Blade Plate must match arbor diameter of blades.
• New cotter pin required each time blade is installed.
• Brush cutters over 16.5 lbs (7.5 kg) dry weight (weight w/o fuel) require a double shoulder harness.
Note: The Barrier Bar is used to restrict rearward movement of the unit. The Barrier Bar is NOT A HANDLE
and should not be gripped when using or carrying the unit.
TO USE
THESE
BLADES
Pro Maxi-Cut
Grass/Weed
Blade
Rigid Plastic
Tri-Cut
Grass/Weed Blade
Metal Blade
You
must
install
these
parts!
Support Handle, w/or
w/o Barrier Bar
U-Handle or Support
Handle
w/Barrier Bar
U-Handle or Support
Handle
w/Barrier Bar
Plastic Shield Plastic Shield Metal Shield
Harness Harness Harness
Upper Plate &
Flat Washer
Upper Plate
& Glide Cup
Upper/Lower
Blade Plates
Hex Nut Hex Nut Hex Nut
New Cotter Pin New Cotter Pin New Cotter Pin
To Next Page
