Echo SRM-2400 TYPE 1E - 09-99 User Manual

GRASS TRIMMER/BRUSH CUTTER
OPERATOR'S MANUAL
13
* Install and use U-Handle when operating any model with blade.
MODEL SRM-2400 1E SRM-2410 1E
Length 1500 mm (59.0 in.) 1500 mm (59.0 in.)
W idth 330 mm (13.0 in.) 600 mm (23.6 in.)
Height 360 mm (14.2 in.) 360 mm (14.2 in.)
W eight (dry) w/Cutting attachment 5.5 kg (12.1 lb.) 5.8 kg (12.7 lb.)
Engine Type Air cooled, two-stroke, single cylinder gasoline engine
Bore
34.0 mm (1.34 in.)
Stroke
2 6 .0 m m (1 .0 4 in.)
D isplacement
23.6 cc (1.44 cu. in.)
E xhaust Spark Arrestor Muffler
Carburetor Walbro diaphragm model W YJ w/purge
Ignition System Flywheel magneto, capacitor discharge
Spark Plug
NGK BPM-7Y, (Gap 0.65 mm (0.026 in.)
Fuel Mixed (Gasoline and Two-stroke Oil)
Fuel/Oil Ratio 50:1 ECHO High Performance, two-stroke air cooled engine oil
Gasoline
89 Octane unleaded. DO NOT use fuel containing methyl
alcohol, more than 10% ethyl alcohol or 15% MTBE.
Oil 50:1 ECHO High Performance, two-stroke air cooled engine oil
Fuel Tank Capacity
0.4 lit. (14.0 US fl. oz.)
Recoil S tarter System Automatic Recoil Starter
Clutch Centrifugal Type
Drive Shaft
1/4" Flex Shaft
Rotating Direction Counter Clockwise viewed from top
Cutter Head Nylon line head (2-line) with .095 Crossfire™
Line capacity 13m (40 ft.)
Handles* D - Loop w/rubber antivibe grip,
Rear rubber grip
U-Handle
U-Handle Optional Standard
Shoulder Harness Optional Standard
Idle Speed 2400 - 3000 RPM
W ide Open Throttle Speed
(W.O.T.) with Nylon Line Head
8800 - 9300 RPM
W ide Open Throttle Speed
(W.O.T.) with Blade (Blade)
9500 - 11000 RPM
SPECIFICATIONS

Echo SRM-2400 TYPE 1E - 09-99 Specifications

General

Brand	Echo
Model	SRM-2400 TYPE 1E - 09-99
Category	Trimmer
Language	English
