12. DISPLAY INFORMATION
Dual frequency mode ※1
18
Longitude
Speed
Direction
Latitude
Voltage Depth unit
Depth
Water temp display
2
nd
echo
Color bar
Shown only under
auto mode.
A
uto mode display
Sweep speed
Frequency display for the
right side
Frequency display for the left side
When using the specific mode, the
selected mode (B/L, Auto Exp, or
Man Exp)
Time marker
Gain bar
30sec bar appears
every minute.
Depth marker
Fish school
200kHz mode
50kHz mode
Depth
Sea bottom
※2
(Optional water temp
sensor is required.)
※1 Frequency display
Display appears differently for single and dual frequency.
※2 Display Lattitude/Longitude/Speed/Direction when connecting to NMEA
(GGA,VTG) device. (Activate NMEA display ON in menu 2.)
