Specifications
<GENERAL>
Power Supply 14.4V DC (11-16V)
Current Drain 3A MAX
Dimensions (W x H x D)
In-Dash Unit 7" x 2" x 6-1/5" (178 x 50 x 158mm)
Mass (weight) Approx. 1.4kg
Usage temperature range -20°C to + 65°C (-4°F to 149°F )
Storage temperature range -40°C to + 85°C (-20°F to 185°F )
<FM TUNER>
Frequency Range
USA: 87.75~107.9MHz (0.2MHz step)
Asia/Australia: 87.5~108MHz (0.05MHz step)
Usable Sensitivity 13dBf
Frequency Response 30~15,000Hz, 3dB
Stereo Separation 38dB
<AM TUNER
>
Frequency Range
USA: 530~1,710kHz (10kHz step)
Asia/Australia: 522~1,629kHz (9kHz step)
Usable Sensitivity 20µV
<CD SECTION>
Frequency Response 20~20,000Hz, 3dB
Wow & Flutter Below measurable limits
Stereo Separation 76dB
S/N Ratio (A-weighted) 90dB
Dynamic Range 89dB
Total Harmonic Distortion 0.02%
<AUDIO AMPLIFIER>
Power Output 13W x 4 (20~20,000Hz, 0.8% THD,
4Ω) Max 40W x 4
Output Level/Impedance 2.7V (0dB) /330Ω line-out
impedance
Tone Action Bass : 10dB at 100Hz
Treble : 10dB at 10kHz
Loudness +9.5dB at 100Hz/+6.0dB at 10kHz
