Eclipse EGO User Manual

Quick Set-Up
Quick Set-Up
Using the Break Beam
Sensor System
To switch off the Break Beam
Sensor System, press and hold the
top pushbutton for one second
(See Figure 2.4).
The eye on icon in the top left
hand corner of the LCD screen
will change to the eye off icon
indicating that the breech sensor
has been disabled.
To switch the Break Beam Sensor
System back on, press and hold the
top pushbutton for one second.
The eye off icon in the top left
hand corner of the LCD screen
will change to the eye on icon
indicating that the breech sensor
has been enabled.
When the Break Beam Sensor
System is enabled, the icon will
change depending on if the system
has detected a ball or not. When
no ball has been detected the icon
looks like this when a ball has
been detected the icon changes to
look like this.
FIGURE 2.4
Note: when turning on the Eclipse Ego, the
Break Beam Sensor System is automatically
enabled.
Quick Set-UpQuick Set-Up
Quick Set-Up
Quick Set-Up
Quick Set-Up
14
15

Eclipse EGO Specifications

General

Air Source	HPA (High Pressure Air)
Body Material	Aluminum
Manufacturer	Planet Eclipse
Type	Electronic
Bore Size	0.689 inches
Barrel Length	14 inches
Battery	9V
Grip Material	Rubber
Color Options	Various
