Advanced Set-Up
The Mode Parameter
The
Mode
Parameter is used to control the firing mode
of the Ego. Please Note: Certain modes may only be
available in certain countries and on certain models of
Eclipse Ego.
Scroll through the
Set-up
menu until the
Mode
parameter
is displayed. The current firing mode is shown on the
right-hand side of the display. To change the
Mode
parameter press
Select
and the edit indicators will
appear
(See Figure 4.8)
Press the
Lower
pushbutton to scroll down through
each of the available firing mode options. Once the
last option has been displayed, pressing the
Lower
pushbutton will cause the first option to be displayed.
Press the
Raise
pushbutton to scroll up through each of
the available firing mode options. Once the first option
has been displayed, pressing the
Raise
pushbutton will
cause the last option to be displayed.
Press the
Select
pushbutton to change the firing mode
to the displayed option.
Selecting
BACK
will return the display to the
Set-up
Menu.
Press the
Lower
pushbutton to scroll down through each of the items on
the
TIMING
Menu. Once the last item has been displayed, pressing the
Lower
pushbutton will cause the first item to be displayed.
Press the
Raise
pushbutton to scroll up through each of the items on the
TIMING
Menu. Once the first item has been displayed, pressing the
Raise
pushbutton will cause the last item to be displayed.
Press the
Select
pushbutton to edit the displayed parameter.
Selecting
BACK
will return the display to the
Set-up
Menu.
The
TIMING
Menu provides access to parameters which control the Ego's
firing cycle.
Scroll through the
Set-up
Menu until
TIMING
is displayed and then press
Select
. This will display
MAX ROF
the first item on the
TIMING
Menu
(See Figure 4.7)
FIGURE 4.7
The Timing Menu
Advanced Set-Up
Advanced Set-Up
30
31
