Maintenance
Cleaning the LPR
Inline regulator can be removed if
needs be.
Unscrew the low-pressure regulator
cap from the marker body
(See Figure 6.20)
.
Remove the LPR piston and
rear spring from the LPR cap
(See Figure 6.21)
.
Cupping the palm of one hand, turn
the LPR cap upside down and tip
the front spring out into your palm
(See Figure 6.22)
.
Remove the rear spring from the
LPR piston and using a dry Q-tip,
carefully clean the seal on the LPR
piston
(See Figure 6.23)
. If the seal
is damaged, replace as necessary.
Once the seal has been cleaned,
lubricate with a light smear of
Vaseline, so that it is ready for re-
assembly.
Note: The adjuster piston
(coloured cap that the front
spring rests in) does not
need to be removed from
the LPR cap for regular
maintenance.
FIGURE 6.22
WARNING
:
De-gas
your marker, discharging any
stored gas in a safe direction,
and remove the barrel and
loader to make the Ego easier
to work on.
FIGURE 6.23
FIGURE 6.20
FIGURE 6.21
Maintenance
Maintenance
44
45
