Eclipse EGO User Manual

Fault FindingFault Finding
Fault Finding
Fault Finding
Fault Finding
Rear QEV leaks. Main rammer seal is damaged. Replace 011 seal on rammer shaft.
Faulty seals inside QEV. Strip QEV and inspect seals for debris
or damage.
Front QEV leaks. Faulty seals inside QEV. Strip QEV and inspect seals for debris
or damage.
Eclipse Ego does not fire. Trigger is set up incorrectly. Set trigger up correctly (see Advanced
Set-up Section).
Solenoid is not plugged into Eclipse
Ego PCB.
Plug solenoid into port on the Eclipse
Ego PCB.
The Break Beam Sensor System is
enabled but there is no paint.
Fill loader with paint.
Low Velocity First Shot FSDO parameter is too low to overcome
stiction on Solenoid and / or Rammer
O-Rings.
Increase FSDO parameter.
High Velocity First Shot FSDO parameter set too high.
Inline Regulator pressure creeping.
Reduce FSDO parameter.
Strip and clean Inline Regulator.
Symptom Possible Cause Solution
Fault Finding
Fault Finding
56
57

Eclipse EGO Specifications

General

Air Source	HPA (High Pressure Air)
Body Material	Aluminum
Manufacturer	Planet Eclipse
Type	Electronic
Bore Size	0.689 inches
Barrel Length	14 inches
Battery	9V
Grip Material	Rubber
Color Options	Various
