Part No Description
Model
1H X1 X3 X5 X7 X9
ECO-777-063 Universal Kwik Mount Klamp Clamps o o o
ECO-777-146 300mm Quick Release Clamp Clamps o o
ECO-777-166 100mm Quick Release Clamp Clamps o o
ECO-777-167 120mm Quick Release Clamp Clamps o
ECO-777-001
Condenser Body, Left Side, 150mm Flat O-Ring Flange,
Vacuum Port 1" OD Pipe on Lower Side and Bottom Ports
Condensers o o o
ECO-777-002
Condenser Body, Right Side, 150mm Flat O-Ring Flange, 1" OD
Pipe on Upper/Lower Side and Bottom Ports
Condensers o o o
ECO-777-091
100mm O-Ring Kettle Flange Condenser with 35/25 O"Ring
bottom and top left side 19/38 Vacuum Port and bottom right
side hose connector, 13” Length
Condensers o o
ECO-777-110
EcoChyll X9 Condenser Body, Left Side,200mm Flat O-Ring
Flange
Condensers o
ECO-777-111
EcoChyll X9 Condenser Body, Middle Side,200mm Flat O-Ring
Flange
Condensers o
ECO-777-112
EcoChyll X9 Condenser Body, Right Side,200mm Flat O-Ring
Flange
Condensers o
ECO-777-113
Condenser Body, Left Side, 120mm Flat O-Ring Flange,
Vacuum Port 1" OD Pipe
Condensers o
ECO-777-114
Condenser Body, Right Side, 120mm Flat O-Ring Flange, 1" OD
Pipe
Condensers o
ECO-777-148
EcoChyll X5 50L Jacketed Condenser Glass Body, 150mm Flat
O-Ring Flange
Condensers o
ECO-777-216 Condenser Body New Descending Right Side 150mm Flange Condensers o o o
ECO-777-217 Condenser Body New Ascending Left Side 150mm Flange Condensers o o o
ECO-777-218 Right Side Jacketed Condenser Body, 150mm O-Ring Flange Condensers o o o
ECO-777-220
Condenser Body, Left Side, 150mm Flat O- Ring Flange,
Vacuum Port with GL-14 Threads Near Top, 1" Swagelock on
Lower Side Out Front and Bottom Ports
Condensers o o o
EcoChyll Parts List
