It may often be necessary to operate the upper circuit at not more than 50% of full power. For low-boiling liquids,
the upper circuit need not be used. When the ask is more than half full of liquid, the two bottom circuits may
be operated at the rated voltage. When the liquid level falls below the halfway mark in the ask, the power to the
upper circuit of the lower half should be reduced to 50% or less. This will prevent the superheating of the vapors
and overheating of the glass fabric in this circuit.
To operate the heating mantle, the following steps can be followed:
1. Power connection: Connect the power cable of the heating mantle to its appropriate temperature controller.
2. Power-on: When connected, the heating mantle immediately starts heating up to the temperature established
on the setpoint controller meter of the temperature controller.
3. Temperature control: The temperature of the heating mantle can only be regulated via the temperature
controller. For desired temperatures, the setpoint controller meter can be used for altering the temperatures.
And the high limit temperature controller meter is engineered to be a safety circuit breaker for conditions
where the mantle heats up beyond the set temperature limit.
WARNING: For maximum safety, the three-prong plug of the cord on the Ecodyst High-Powered Heating Mantles
should always be inserted into a grounded outlet; thus, the receptacle of only the Ecodyst-approved heating
mantle controller for the specic mantle.
1. When using this equipment, use caution. Before utilizing it, users should read this manual. The equipment
should only be used by laboratory professionals who have been professionally trained for this purpose and are
familiar with all laboratory safety precautions.
2. If unusual sounds, odors, or smog are produced, disconnect the controller’s main plug and contact the
manufacturer or supplier. It is usual to experience smog or smell while using the machine for the rst time. Any
further incidents should be handled as soon as possible by contacting the manufacturer or supplier.
3. Other than the correct size of the reaction vessel, no objects should be placed within the machine. When a
conductive material, such as cloth, metal, or paper, is placed inside the heating mantle, it might produce a re,
or electric shock, or even cause the machine to break down.
4. Do not attempt to disassemble or redesign the equipment on your own. It may compromise the device’s
intended safety. Ecodyst Scientic, Inc. shall not be liable for any accident, decrease in quality, or defect caused
by a client or user who disregards this.
5. The manufacturer designed and developed all of the mechanical and electrical/electronic gadgets in this
machine. The gadgets could only be dismantled and serviced by one of the manufacturer’s engineers or by
engineers authorized by the manufacturer.
6. While operating, avoid using a wet hand on the device.
7. The heating mantle might reach temperatures of 400 degrees Celsius or more. When this surface, particularly
the reaction vessel, is in use, it can cause signicant harm, including burns from the heated surface.
8. Do not switch the machine on and o frequently.
Operational Safety
High Powered Heating Mantle
