Assembly
• This user manual only provides the cable connection method and the mounting method for
the microinverter. For installing the solar panel, please refer to the instructions for the solar
panel and its accessories.
• If you wish to verify the solar system, complete the assembly on a sunny day.
Select a location for the PowerStream Microinverter
Pre-assembly
Make sure that the microinverter is within the Wi-Fi coverage.
2.4G
2.4G
The IP rating of the microinverter is IP 67, hence, it can be installed either indoors or outdoors.
However, the EcoFlow portable power station is not waterproof. If your system includes a
portable power station, keep both of them indoors.
Do not place or install the microinverter in an area where ammable or explosive materials
are stored.
