|8
Measure the distance
Extension cable 3 m
Super flat cable 0.5 m
BKW-Solar cable 2 m
BKW-AC cable
1.5 m/3 m/5 m
Battery connection cable
0.4 m /0.5 m /1 m
USB port
Logic
interface
Assembly procedure
Place the microinverter on the EcoFlow portable power station.
• The lengths of cables vary in different countries or regions. Please refer to the
actual products.
• Except for the standard BKW-Solar cable and the BKW-AC cable, other cables
need to be purchased from the ofcial website.
• If you need to mount the microinverter, please refer to "Mounting the
Microinverter".
• To cool the microinverter to optimal temperature, you can install the EcoFlow
Smart Cooling Deck (sold seperately), as the gure shown below.
