EcoFlow PowerStream Microinverter - Mounting the Microinverter

15|
1. Use the installation board to locate the hole and drill two holes about 41 mm deep in the
wall. Then, insert M5x40 into the holes.
Mount on the wall
100W
Solar panel 1
100W
Solar panel 3
100W
Solar panel 2
100W
Solar panel 4
M
M
C
K
L
Mounting the microinverter
• Wear protective goggles or gloves when drilling holes.
41mm
×1
D
×2
F
Diller Ф8 mm
