EcoFlow PowerStream Microinverter - Specifications

|28
Specifications
General info
Model EFWN511/EFWN511B
Dimension 242×169×33 (mm)
Weight Approximately 3 kg
PV port
Operating voltage 11 - 55 Vd.c.
Maximum input voltage 55 Vd.c.
Maximum input current 13 A
Initial input voltage 15 Vd.c.
Anti-reverse connection protection
Supported
Overvoltage
Ⅱ
Max. PV short circuit current (Isc PV) 14 A
Max. inverter backfeed current to the array 0 A
Number of MPPTs 2
BAT / DC port
Discharging mode
Maximum input current 13 A
Input voltage 11 -15 Vd.c. , 40 - 59 Vd.c.
Maximum input voltage 59 Vd.c.
Charging mode
Charging voltage 30 - 58 Vd.c.
Maximum charging current 13 A
Rated charging voltage 48 Vd.c.
Overvoltage
Ⅱ
Battery input short circuit
current rating
20 A
