EcoFlow Wave 2 User Manual

14
The air inlet may be blocked by large amount of dusts and impurities in the air during outdoor
application.Please regularly remove the front and rear air inlet lters, clean them with a damp
cloth with mild detergent, dry them in the air, and then reassemble them.
How to Clean
Manual drainage: A small amount of residual water will be left at the bottom of the water
tank after automatic drainage. Please turn the drainage outlet connector counterclockwise to
remove it, and tilt the unit back slightly until the condensate is completely drained to prevent
breeding of bacteria.
Front Front
air inletair inlet
Rear Rear
air inletair inlet

EcoFlow Wave 2 Specifications

General

Type	Monobloc mobile air conditioner
Wi-Fi	Yes
Noise level	56 dB
Refrigerating medium	R290
Cooling capacity (max)	5100 BTU/h
Heating capacity (max)	6100 BTU/h
Air conditioner functions	Cooling, Heating
Operating temperature (T-T)	5 - 50 °C
Refrigerating medium weight	130 g
Suitable for room area up to	10 m²
Cooling capacity in watts (max)	1500 W
Heating capacity in watts (max)	1800 W
International Protection (IP) code	IPX4
Cooling capacity in watts (nominal)	- W
Heating energy efficiency (COP, W/W)	-
Connected load	820 W
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Power consumption (cooling)	550 W
Power consumption (heating)	600 W
Hourly energy consumption (cooling)	- kWh
Product color	Black, Grey

Weight and Dimensions

Depth	297 mm
Width	518 mm
Height	336 mm
Weight	14500 g
