CH Supply
CH supply sensor
201-0196
106-0435
16
CH Supply
Magnetite Filter C/H100 C/H140
202-1023
106-1278
16
CH Supply
Magnetite Filter C/H200
202-1179
106-1279
18
Hydroblock
IWC Hydroblock C/H100 C/H140
202-1235
106-1272
18
Hydroblock
IWC Hydroblock C/H200
202-1236
106-1273
18
Hydroblock
SPARE PUMP HEAD
206-0463
106-1259
C/H100 & C/H140
18
Hydroblock
SPARE PUMP HEAD C/H200
206-0464
106-1260
18
Hydroblock
O-Ring Hydroblock D18 (o-ring
202-0130
106-1099
CH connections hydroblock)
18
Hydroblock
O-ring Hydroblock D10
202-1080
106-1092(10pcs)
(expansion vessel pipe
connection)
18
Hydroblock
O-ring Hydrocoupling (connection
202-1081
106-1093(10pcs)
pipe hydroblock left/right)
18
Hydroblock
Plug D10 (expansion vessel
202-1124
106-1094(5pcs)
connection closing plug)
18
Hydroblock
O-ring Hydroblock D12 (o-ring
202-1129
106-1096(10pcs)
DHW connections hydroblock)
18
Hydroblock
Metal clip D10 (mouting clip for
202-1136
106-1097(5pcs)
expansion vessel connection)
18
Hydroblock
Plastic quick connect clips for
202-1139
106-1098
Hydroblock connections, D18
(Quick connection clips for pipes
to PHE)
19
Flow Sensor
Flow Sensor
206-0432
109-1062
3-WAY VALVE MOTOR
206-0431
109-1059
20
Pressure sensor
Pressure sensor
202-1135
106-1061
21
Burner control
HAG-C04-IT02 Canada
202-1233
106-1243
SERIGRAFIA
21
Burner control
CABLE FOR HAGC04 TO
202-1044
106-1048
DISPLAY
21
Burner control
DISPLAY AQUAMAX
202-1045
22
Exterior Housing
Front Housing
23
Cable tree
Cable tree 1 sensor & stepper
Motor
23
Cable tree
Cable tree 2 Gas Valve
23
Cable tree
Cable tree 4 Sensor Flue Temp
23
Cable tree
Cable tree 6 Spark plug
202-1216
106-1244
23
Cable tree
Cable tree 8 Ignition ground Cable
23
Cable tree
Cable tree 5 Fan & Pump
23
Cable tree
Cable tree 9 Ground Plumbing
23
Cable tree
POWER Cable
24
Expansion tank
Internal expansion tank
202-1012
106-1069
25
Automatic air vent
AUTOMATIC AIR VENT
206-0434
106-1065
Pressure relief valve
Pressure relief valve (Watts type
202-1246
106-1240
374A)
Seal gasvalve connections
O RING 3/4" UNITEC 300
202-0135
106-1101
Seal expansion vessel
O RING 1/2" UNITEC300
202-0136
106-1102
connection
Seal hydro connection
O RING 3/4" NBR
202-0137
106-1103
adapters
Table 13.1. Parts list EcoKing
68
