4 Functional description
This is a Dermados Station stand-alone device with touch-free operation for safe
application of hand disinfectants.
The dispensers are also suitable for dosing liquid soaps and lotions. The integrated
sensor detects an approaching hand and triggers an automatic dispensing process.
It Dermados Station is used in entrance areas of office buildings, hotels, hospitals, food
and beverage manufacturers, cosmetics, pharmaceutical and other industrial companies
as well as schools, kindergartens and supermarkets.
It is a battery-powered system that can be set up autonomously
.
It Dermados Station is available in different versions, so that it can be operated with a 5 or
20 l canister or with 500 and 1000 ml bottles, depending on the version (see also
Ä
Chapter 4.1 ‘Variants’ on page 19).
The 5 and 20 l versions are particularly suitable for highly frequented disinfection
processes, as the large volume of the disinfection container means that canisters do not
need to be replaced as often. With the 20 l version, over 6000 dosages are possible
without canister or battery change.
As a further version of the 5 or 20 l version, a "rollable" version is optionally available.
This version facilitates installation and is particularly advantageous if the station is to be
relocated.
General set-up
1 Housing corpus
a
Lock
b
ON / OFF switch (+ special function)
c
Adjustment button for dispensing quantity
(+ special function)
d
Dispenser pump, writable
e
Battery compartment
f
Sensor mounting plate
g
LED
h
Nozzle
i
Dosing hose to nozzle (short)
j Dosing hose to canister (long)
k Cylinder holder
2 Housing cover
l
Latch
3 Drip tray
4 Floor-mounted console
5 Dosing agent box for 5 and 20 l canisters
Functional description
18MAN048961, Rev. 2-09.2020
