12 Technical specifications
In this chapter you will find the technical data of the Dermados Station.
Specification Value
Housing material incl. mounting plate ABS-plastic, impact-resistant
Pump material ABS plastic
Hose material Silicon
Colour: Housing and mounting plate white/grey
Batteries 4 x 1,5 V AA Mignon LR6
Data Value Unit
Voltage 6 V
Protection rating IP 22
Weight of console (single) approx. 19 kg
Weight of dosing dispenser (single and excl.
batteries)
approx. 0.85 kg
Total weight approx. 20 kg
Deformation temperature > 85 °C
12.1 Type plate
The rating plate is located at the top on the reverse side of the Dermados
station.
Fig. 9: Type plate
1 Type designation
2 Serial number
3 Specification of the noise level
4 Production code
5 CE conformity
6 Manufacturer's address
Technical specifications
42MAN048961, Rev. 2-09.2020
