4.2.2.1 Calibration




SEL
DETERGENT UNIT
04.50 kg/cap


SEL
RINSE AID UNIT
00.00 ml/min
ZERO CALIBRATION
CONDUCT. SENSOR
CALIBRATE RINSE
TEMPERATURE ?
CALIBRATE WASH
TEMPERATURE ?


WASH TEMPERATURE
55C ( 0)
RINSE TEMPERATURE
80C ( 0)
ml/hr
ml/min
l/hr
l/min
g/hr
g/min
kg/hr
kg/min
kg/cap
kg/bag
RUNNING
PLEASE WAIT
CALIBRATIONFAULT
PUSH ANY BUTTON


SEL
NEXT
CALIBRATION
OK


SEL
NEXT


ARE YOU SURE ?
NO 0.0 mS 55C
CALIBRATION
FUNCTIONS
SEL
SEL SEL SEL
BACK
Programming Structure
Programming Structure
ECOPLUS (complete)
ECOPLUS (complete)
Software v2.00
Legend:
Basic
T-Version
+
X-Version
+
Issue: 2007-19


SEL
3RD PROD. UNIT
00.00 ml/min
To proceed from one menu to the next press
NEXT
NEXT button.
Back to the starting level.


Press this button to proceed to a submenu,
or to scroll within a menu.
To increase a value within a menu.
To decrease a value within a menu.
Only visible if the corresponding function is activated.
SEL
( )
ml/hr
ml/min
l/hr
l/min
g/hr
g/min
kg/hr
kg/min
