Ecolab Ecoplus-PCB User Manual

417101726_Ecoplus_PCB.docx
- 37 -
Rev. 02-02.2012
7 Fault Handling
You can switch off the acoustic alarm by pressing any key on the front of the device.
However, the alarm display on the screen remains visible until you eliminate the fault.
Display screen message
Cause of fault
Remedy
NO DETERGENT
CHANGE CONTAINER
The detergent storage unit is empty.
Connect a new storage unit.
The alarm delay time tmax (DET. DELAY TIME)
is too short.
Change the alarm delay time.
The booster concentration value is too high.
Change the concentration value
for the booster function.
NO CAPSULE
No capsule inserted.
Insert capsule.
Defective capsule switch.
Replace capsule switch.
COVER OPEN
Cover open.
Close cover.
Cover-PCB defective.
Replace cover.
DETERGENT OVERFLOW
TRIAC for the activation of the 'meter detergent’
output defective.
Replace the motherboard.
Alarm delay time (DET. OVERDOSAGE
DELAY) too short.
Change the alarm delay time.
SENSOR FAULT
Defective conductivity measuring cell or
connector cable; connection not correct.
Check connection; change
conductivity measuring cell if
necessary.
Measuring sensor for rinsing water temperature
defective, connector cable defective, or
connection not correct.
Check connection, replace
measuring sensor if necessary.
SYSTEM FAULT
No. 2
Real-time module defective.
Replace the motherboard.
No. 3
Hook-up switch in incorrect position.
Move switch into correct
position.
No. 4
No. 4: EEPROM defective.
Replace the motherboard.
No. 5
Defective peristaltic pump.
Replace peristaltic pump.
No. 6
Error in zero-point calibration.
Switch off the device, empty the
dishwasher, and restart the
filling process.
NO RINSE AID
CHANGE CONTAINER
Rinsing agent storage unit empty.
Connect a new storage unit.
Defective suction lance, defective connector
cable.
Replace the suction lance.
NO 3RD PRODUCT
CHANGE CONTAINER
Additional product storage unit empty.
Connect a new storage unit.
Defective suction lance, defective connector
cable.
Replace the suction lance.
LOW TANK/RINSE
TEMPERATURE
This alarm is issued as soon as the delay time
for the alarm has expired if the wash tank/rinse
temperature falls before the minimum permitted
value (LO).
Defective dishwasher.
Change the temperature limits
value or change the alarm
delay time.
HIGH TANK/RINSE
TEMPERATURE
This alarm is issued as soon as the delay time
for the alarm has expired if the wash tank/rinse
temperature rises above the maximum
permitted value (HI).
Defective dishwasher.
Change the temperature limits
value or change the alarm
delay time.
DISABLE ALARM
This alarm is issued if the metering unit was in
operation during idle time (= the period of time
defined as shut-down time for the dishwasher).
If necessary, change the times
for the operating shifts or switch
off the dishwasher.
FINAL RINSE
STUCK ON
For single-tank industrial dishwashers:
Rinsing agent metering device in operation
longer than pre-programmed (rinse program
does not switch off).
Switch off the dishwasher rinse
program.
FINAL RINSE
LOW FLOW
For multi-tank industrial dishwashers: Rinsing
agent metering device in operation even though
water infeed has been interrupted.
Check the water supply. Clean
the rinsing nozzles and replace
them if necessary.
DRAIN AND REFILL
THE WASH TANK
This alarm is issued as long as the delay time
for the alarm has expired if the defined interval
since the last drainage of the detergent solution
has been exceeded.
Drain the washing tank.
