Ecolab Ecoplus-PCB User Manual

417101726_Ecoplus_PCB.docx
- 39 -
Rev. 02-02.2012
9 Technical Data
Power supply:
2x12 V, 50-60 Hz
Power:
Motherboard w/o add-on board:
15 W
With 32355103 peristaltic pump add-on
board:
30 W
With 32355202 KA add-on board:
Max. 45 W
Protection class:
As appropriate for metering devices
Protection rating:
III (except PCB, without transformer)
Inputs:
Motherboard:
- 2 x 12 V AC power supply
- Inductive measuring cell with integrated washing tank temperature
sensor
- Rinse temperature sensor
- 5 V AC empty signal input/capsule switch
Add-on board:
- 24 V AC ‘dose detergent’ enable signal
- 24 V AC ‘pre-proportion detergent’ enable signal
- 24 V AC ‘dose rinsing agent’ enable signal
- 5 V AC rinsing agent empty signal
- 5 V AC additional product empty signal
- Power supply for external additional product metering pump (via
240/24 V AC transformer; 30 W)
Mains cut-off
module(s):
- 3 inputs (wash, pre-proportioning, rinse)
- 18 … 240 V AC/DC
- External back-up fuse, max. 16 A per input
Outputs:
Motherboard:
- 24 V AC detergent metering, max. 45 W*
- 24 V AC rinsing, max. 30 W*
- 24 V AC fault signal, max. 30 W*
Add-on board:
- Rinsing pump
o With 32355103: 24 V DC (peristaltic pump), max. 10 W
o With 32355202: 24 V AC, max. 45 W
- 3rd product, 24 V AC
o With 32355202: 24 V AC, max. 45 W (external transformer)
RS 232 printer:
- Protocol: XON/XOFF
- Baud rate: 9600 bits/sec
- 1 start bit
- 8 data bits
- 1 parity bit (no parity)
- 1 stop bit
*) The total output power may not exceed the transformer capacity.
Conductivity measurement:
Measurement
range:
0 -100 mS/cm
in steps of 0.1 mS/cm (0.1 - 19.9 mS/cm)
in steps of 1 mS/cm (20 - 100 mS/cm)
Automatic range switchover:
0 - 3 mS/cm
0 - 10 mS/cm
0 - 30 mS/cm
0 - 100 mS/cm
Precision:
± 10% of the set conductivity value < 3 mS/cm
± 2.5% of the set conductivity value > 3 mS/cm
Reproducibility:
Amplitude variation of
±
2.5% of set value
Real-time clock:
With battery buffering (lifetime > 10 years)
Delay time for lack of detergent:
0 – 999 seconds
Pre-proportioning time:
0 – 999 seconds
Fault memory:
Maximum of 50 faults including time, date, and operating time
Peristaltic pump speed
(with 32355102):
10 - 100 % (around 4 - 40 rpm)
Environmental temperature:
Max. 50°C
Dimensions:
135 x 99 x 35 mm (W x D x H)
Weight:
Approx. 0.2 kg (with peristaltic pump add-on board)
INFORMATION
We reserve the right to make technical changes in order to make sure that our
products correspond to the most recent state of technology.
