Ecolab SCLS IV - Specifications

2.2 Specifications
The following section discusses the cabinet space and service access requirements:
2.2.1 Dimensions
The dispenser module assembly has the following dimensions.
• Height....................20 1/4” (including standpipe 22”)
• Width ....................10 1/4”
• Depth .....................11”
• Weight...................15 lbs. (with product up to 21 lbs.)
• Product clearance needs to be 8” above the cabinet to replace product capsules.
2-2
SCLS IV/AQUANOMIC EU IV Dispensing Module Installation & Operation Manual
W
Figure 2-1
