CONTROL VALVE PROGRAMMING AND COVER DRAWING MANUAL
This manual is the intellectual property of Ecoso. Copying and reprinng is prohibited. © 2021
ANNEX. DRAWINGS OF CONTROL VALVE PARTS
Drawing No. Order No.  
1 V3176 Injector Cap 1
2 V3152 O-Ring 135 1
3 V3177 Injector Screen 1
4 V3010-1Z  1
5
V3010-1A 
1
V3010-1B 
V3010-1C 
V3010-1D 
V3010-1E 
V3010-1F 
V3010-1G 
V3010-1H 
V3010-1I 
V3010-1J 
V3010-1K 
Not Shown V3170 O-ring 011 *
Not Shown V3171 O-ring 013 *
Injector Cap, Injector Screen, Injector, plug and O-Ring



injector plugs are located in both holes.
