CONTROL VALVE PROGRAMMING AND COVER DRAWING MANUAL
This manual is the intellectual property of Ecoso. Copying and reprinng is prohibited. © 2021
ANNEX. DRAWINGS OF CONTROL VALVE PARTS
Drawing No. Order No.  
1 V3005 WS1 Spacer Stack Assembly 1
2 V3004  1
3 V3178 WS1 Drive Back Plate 1
4a V3011* 
1
4b V3011-01* 
5 V3174 WS1 Regenerant Piston 1
6 V3175 O-ring 228 1
7 V3180 O-ring 337 1
8 V3105  1
Not Shown
V3001 
1
V3001-02 
V3001UP 
V3001-02UP 
WS1CI Drive Cap Assembly, Downow Piston, Upow Piston, Regenerant Piston
and Spacer Stack Assembly
Drawing number parts 2 through 6 may be purchased as a complete assembly, part V3002CI
