Ecosoft WS1 CE - Page 31

31
ENG
CONTROL VALVE PROGRAMMING AND COVER DRAWING MANUAL
This manual is the intellectual property of Ecoso. Copying and reprinng is prohibited. © 2021
V4017-01 T1 Interconnect Fing Assembly
D1400 1191 In/Out Head
ANNEX. DRAWINGS OF CONTROL VALVE PARTS
Drawing No. Order No.  
1 V3151

4
2 V3150  4
3 V3105 O-RING 215 4
4 V4017  2
Drawing No. Order No.  
1 V3180  1
2 V3105  1
