3. Operating your Pellet Fire
3.1 Description of the Controls
3.2 Description of Remote control
IR receiver for remote control (12 volts batteries code LRV08 not included).
3.3 Switching on the Stove
1. Ensure burn pot is clean and free of ash
2. Slide the heat exchange cleaner in and out three times
3. To turn unit on hold down button ‘3’ (ON/OFF)
4. Control Screen will show START
5. Use buttons ‘1’ or ‘2’ to select desired heat
6. Use buttons ‘4’ or ‘5’ to select desired thermostat setting
7. To turn unit off hold down button ‘3’ (ON/OFF)
8. Control Screen will show FINAL CLEANING
3.4 Operating Precautions
• In case of faulty operation turn the stove off pressing button no. 3.
• Do not manually load the re pot with pellets.
• Any build up of unburned pellets inside the re pot after repeatedly trying to light the
stove, must be removed before further attempts.
• Do not use any fuels other than wood pellets.
• Should the ignition system be faulty, do not attempt to light the stove using ammable
materials.
3.5 Priming of the Screw (Auger)
To prime the screw/auger (when the stove is new or has been completely run out of fuel, the loading
20°C
10:00 20°C
OFF
P1 : Turns heat level down
P2 : Turns heat level up
P3 : Turns ire on-off
P4 : Turns thermostat down
P5 : Turns thermostat up
P6 : Menu button
P7 : Menu button
1
2
4
5
• P1 - P2 Temperature setting: allow setting the value of the desired
room temperature from a maximum of 40°C to a minimum of
6°C.
• P4 - P5 Power setting: allows setting the value of the working
power from a minimum of 1 to a maximum value of 5 displays.
• P1 + P4 ON/OFF: pressed for 2 seconds, they switch on and off
the stove manually.
Heat Exchange
Cleaner/Scraper
