ECOVACS DB3G.21 - Package Contents and Technical Specifications; Package Contents Overview; Technical Specifications

6
EN
2.1 Package Contents
Robot
Sponge Filter and
Main Brush Option Battery Pack
Cleaning Cloths
Advanced Wet/Dry
Reservoir
Charging Dock Remote Control Instruction Manual+
Quick Start Guide
Model DB3G.21
Working Voltage 12V DC Rated Power 40W
Battery Model DN700-BYD
Ni-MH 12 V DC,
3000 mAh
Charging Dock Model CH1465A
Rated Input Voltage 100-240V AC Rated Output Voltage
20V DC
Rated Output Current 1A Rated Power 20W
Remote Control Model RC1507
Remote Control Battery
Model
AAA
Remote Control Battery Input
Voltage
1.5V DC
Remote Control working
voltage
3V DC
Frequency bands 2412-2472MHz
Maximum RF power transmitted
in the frequency band
Max PA output power at 72.2 Mbps: 17.5 dBm
Max PA output power in 11b mode: 21.5 dBm
*
Measuring Cup
