38
Using BIOS
Onboard LAN Device (Enabled)
This option allows you to enable or disable the onboard LAN function.
Onboard LAN Boot ROM (Disabled)
Use this item to enable and disable the booting from the onboard LAN or a network add-in
card with a remote boot ROM installed.
USB Keyboard Support (Enabled)
This item allows the BIOS to interact with a USB keyboard or mouse to work with MS-DOS
based utilities and non-Windows modes.
USB Mouse Support (Enabled)
Enable this item if you plan to use a mouse connected through the USB port in a legacy
operating system (such as DOS) that does not support Plug and Play.
AC97 Audio (Auto)
This option allows you to control the onboard AC97 audio. Disable this item if you are
going to install a PCI audio add-on card.
AC97 Modem (Auto)
fSuperIO Device
Scroll to this item and press <Enter> to view the following screen:
POWER ON Function [Hot Key]
KB Power ON Password [Enter]
Hot key Power ON [Ctrl-F12]
Onboard FDC Controller [Enabled]
Onboard Serial Port1 [3F8/IRQ4]
UART 2 Mode Control [Disabled]
UART Mode Select [Normal]
RxD , TxD Active [Hi, Lo]
IR Transmission Delay [Enabled]
UR2 Duplex Mode [Half]
Use IR Pins [IR-Rx2Tx2]
Onboard Parallel Port [378/IRQ7]
Parallel Port Mode [ECP]
ECP Mode Use DMA [3]
Power On After Power Fail [Off]
Phoenix-AwardBIOS CMOS Setup Utility
SuperIO Device
Item Help
ff
Menu Level
POWER ON Function (Hot Key)
This feature allows you to set the method by which your system can be turned on.
: Move Enter: Select +/-/PU/PD:Value F10:Save ESC:Exit F1: General Help
mnlk
F5:Previous Values F6:Fail-Safe Defaults F7:Optimized Defaults
Use this item to enable or disabled the onboard AC97 modem device.
Press <Esc> to return to the AwardBIOS CMOS Setup Utility page.
