25
Installing the Motherboard
ATX12V: ATX 12V Power Connector
Pin Signal Name
4 +12V
3 +12V
2 Ground
1 Ground
PWR_FAN: FAN Power Connector (optional)
Pin Signal Name Function
1 GND System Ground
2 +12V Power +12V
3 NC Not connect
