18
Installing the Motherboard
LPT: Onboard parallel port Header
This is a header that can be used to connect to the printer, scanner or other devices.
1 STROBE 14 AFD
2 PD0 15 ERROR
3 PD1 16 INIT
4 PD2 17 SLCT
5 PD3 18 Ground
6 PD4 19 Ground
7 PD5 20 Ground
8 PD6 21 Ground
9 PD7 22 Ground
10 ACK 23 Ground
Pin Signal Name Pin Signal Name
11 BUSK 24 Ground
12 PE 25 Ground
13 SLCT 26 Key
