7
Introducing the Motherboard
Table of Motherboard Components
This concludes Chapter 1. The next chapter explains how to install the motherboard.
LABEL COMPONENTS
1. CPU
Supports the LGA1155 socket for 2
nd
/3
rd
Generation Intel
®
Ivy/Sandy Bridge Processor
2. CPU_FAN CPU cooling fan connector
3. DIMM1~4 240-Pin DDR3 SDRAM slots
(Channel A: DIMM2, DIMM4 Channel B: DIMM1, DIMM3)
4. TPM Trusted Platform Module header
5. PRINTER Onboard parallel port header
6. ATX_POWER Standard 24-pin ATX power connector
7. BZ1 Buzzer
8. USB3F Front panel USB 3.0 connector
9. SATA1 Serial ATA 6.0Gb/s connector
10. SATA3~5 Serial ATA 3.0Gb/s connectors
11. F_PANEL Front panel switch/LED header
12. C_INTRUSION Opened Chassis detective header
13. CLR_CMOS Clear CMOS header with jumper
14. ME_DISABLE ME Disable header with jumper
15. BIOS_WP BIOS flash protect header with jumper
16. F_USB2 Front panel USB 2.0 header
17. F_USB1 Front panel USB 2.0 header (for card reader)
18. INT_SPK Speaker header
19. F_AUDIO Front panel audio header
20. PCI1~2 32-bit add-on card slots
21. PCIE1X_1 PCI Express x1 slot
22. PCIE16Х PCI Express x16 slot
23. SYS_FAN System cooling fan connector
24. COM2 Onboard serial port header
25. ATX_12V1 Auxiliary 4-pin power connector
