B75H2-M4 USER MANUAL
32
Chapter 3
PC Health Status
On motherboards support hardware monitoring, this item lets you monitor the
parameters for critical voltages, temperatures and fan speeds.
Scroll to this item and press <Enter> to view the following screen:
Smart Fan Function
CPU/System Smart Fan Control (Enabled)
This item allows you to enable/disable the control of the CPU/System fan speed by
changing the fan voltage.
Main Advanced Chipset M.I.B III Boot Security Exit
+/- : Change Opt.
Enter/Dbl Click : Select


: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
CPU Smart Fan Control Enabled
Smart Fan Mode Normal
Smart Fan start PWM value 180
Smart Fan start PWM TEMP(-) 30
DeltaT 3
Smart Fan Slope PWM value 10 PWM value/unit
CPU Fan Full Speed Offset (-) 23
Main Advanced Chipset M.I.B III Boot Security Exit
+/- : Change Opt.
Enter/Dbl Click : Select


: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
System Temperature : 24
0
C
CPU Fan Speed : 0 RPM
System Fan Speed : 0 RPM
CPU Voltage : 1.152V
DIMM Voltage : 1.548V
+5V : 5.160V
+12V : 11.952V
-=- PECI Mode -=-
Offset to TCC Activation Temp. : -47
Smart Fan Function
PC Health Status
Smart Fan start PWM value 180
Smart Fan start PWM TEMP(-) 30
DeltaT 3
Smart Fan Slope PWM value 10 PWM value/unit
System Fan Full Speed Offset (-) 23
System Smart Fan Control
Smart Fan Mode Normal
Enabled
