Chapter 1
2
B75H2-M4 USER MANUAL
CPU
Specifications
• Intel
®
B75 ChipsetChipset
• Dual-channel DDR3 memory architecture
• 2 x 240-pin DDR3 DIMM sockets support up to 16 GB
• Supports DDR3 1600/1333/1066 MHz DDR3 SDRAM
Memory
• 1 x PCI Express x16 Gen3* slot
(*Intel Ivy Bridge CPU required.)
• 1 x PCI Express x1 slot
• 1 x PCI1 slot
• Supported by Intel
®
B75 Express Chipset
- 3 x Serial ATA 3Gb/s devices
- 1 x Serial ATA 6Gb/s device
Expansion
Slots
Storage
• 1 x PS/2 keyboard and PS/2 mouse combo connector
• 4 x USB 2.0 ports
• 1 x HDMI port (or DVI port)
• 1 x VGA port
• 2 x USB 3.0 ports compatible to both USB 3.0/2.0 devices
(blue)
• 1 x RJ45 LAN connector
• 1 x Audio port (1x Line in, 1x Line out, 1x Mic_in Rear)
Rear Panel I/O
LAN • Realtek RTL8111E Gigabit Lan
- 10/100/1000 Fast Ethernet Controller
- Wake-on-LAN and remote wake-up support
• LGA1155 socket for 2
nd
/3
rd
Generation Intel
®
Sandy/Ivy Bridge
Processors
• Supports New 22nm Intel
®
Core
TM
micro-architecture
• DMI 5.0GT/s
Note: Please go to ECS website for the latest CPU support list.
Note: Please go to ECS website for the latest Memory support list.
• 1 x 24-pin ATX Power Supply connector
• 1 x 4-pin 12V Power connector
• 1 x 4-pin CPU_FAN connector
• 1 x 3-pin SYS_FAN connector
• 2 x USB 2.0 headers support additional four USB 2.0 ports
• 1 x USB 3.0 header supports additional two USB 3.0 ports
• 3 x SATA 3Gb/s connectors
• 1 x SATA 6Gb/s connector
• 1 x COM header
• 1 x Case open header
• 1 x SPDIF out header
• 1 x CLR_CMOS header
Internal I/O
Connectors &
Headers
• Realtek ALC662 (colay: VT1705CF)
- 6 Channel High Definiton Audio Codec
- Compliant with HD audio specification
Audio
