ECS B75H2-M4 User Manual

B75H2-M4 USER MANUAL
46
Chapter 3
CPU OverClocking Configuration
Scroll to this item to view the following screen:
Aptio Setup Utility - Copyright (C) 2012 American Megatrends, Inc.
This page enables you to set the clock speed and system bus for your system. The
clock speed and system bus are determined by the kind of processor you have
installed in your system.
M.I.B III (MB Intelligent BIOS III) Menu
ME Subsystem Help
Main Advanced Chipset M.I.B III Boot Security Exit
+/- : Change Opt.
Enter/Dbl Click : Select


: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
CPU OverClocking
Configuration
M.I.B III (MB Intelligent BIOS III)
CPU OverClocking Configuration
Chipset OverClocking Configuration
B.O.M.P Technology Enabled
Auto Detect DIMM/PCI Clk Enabled
Spread Spectrum Enabled
Intel(R) Core(TM) i7-2600 CPU @ 3.40GHz
Processor Speed 3400 MHz
Memory Frequency 1333 MHz
Total Memory 2048 MB (DDR3 )
Enabled
Disabled
0
10
38
37
36
35
0
Main Advanced Chipset M.I.B III Boot Security Exit
+/- : Change Opt.
Enter/Dbl Click : Select


: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
Enhanced Intel SpeedStep
Technology
Intel Graphics Configuration
Graphics Core Ratio Limit 27
Graphics Voltage(1/256)
CPU OverClocking Configuration
CPU Frequency 100.00
CPU Ratio 34
Enhanced Intel SpeedStep Technology Enabled
Turbo Mode
Runtime Turbo Enable Disabled
Over Clocking Extra Vo1.(1/256 V) 0
IA Core Current Maximum
iGFX Core Current Maximum
Long Duration Power Limit Override Maximum
Long Duration Maintained 10
Short Duration Power Limit Override Maximum
1 Core Ratio Limit 38
2 Core Ratio Limit 37
3 Core Ratio Limit 36
4 Core Ratio Limit 35
0
Enabled
