B75H2-M4 USER MANUAL
47
Chapter 3
Enhanced Intel SpeedStep Technology (Enabled)
This item allows users to enable or disable the EIST(Enhanced Intel SpeedStep Tech-
nology).
Graphics Voltage(1/256) (0)
This item allows you to adjust the internal GFX voltage.
Graphics Core Ratio Limit (27)
This item allows you to control the internal GFX Turbo ratio.
CPU Ratio (34)
This item allows users to control non turbo CPU ratio.
System Temperature :
CPU Fan Speed :
System Fan Speed :
CPU Voltage :
DIMM Voltage :
+12V
CPU Frequency (100.00)
This item shows the information of the CPU frequency.
Turbo Mode (Enabled)
This item allows you to control the Intel Turbo Boost Technology.
Runtime Turbo Enable (Disabled)
This item shows if CPU support Runtime Turbo.
IA Core Current (Maximum)
Use this item to control CPU Current Limit.
iGFX Core Current (Maximum)
Use this item to control iGFX Core Current Limit.
Long Duration Power Limit Override (Maximum)
Intel(R) Turbo Boost Technology will use this power limit during the Long Duration
Power Limit Time Window.
Long Duration Maintained (10)
Use this item to control the time window over PL1 Value should be maintained. This
is for Turbo Mode.
Short Duration Power Limit Override (Maximum)
Intel(R) Turbo Boost Technology will use this power limit for a very short duration.
After that, the Long Duration Power Limit will be honored .
1/2/3/4 Core Ratio Limit
This item shows the Core Ratio Limit Value.
Overclocking Exrra Vol. (1/256 V) (0)
This item allows you to control Extra CPU Voltage.
