ECS G41T-M7 User Manual

35
Using BIOS
Integrated Peripherals
This page sets up some parameters for peripheral devices connected to the system.
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
Integrated Peripherals
Onboard IDE Controller Enabled
Onboard SATA Controller Enhanced
Onboard Audio Function Enabled
Onboard LAN Function Enabled
Onboard LAN Boot ROM Disabled
Serial Port1 Address 3F8/IRQ4
Parallel Port Address 378
Parallel Port Mode ECP
ECP Mode DMA Channel DMA3
Parallel Port IRQ IRQ7
USB Functions Enabled
Legacy USB Support Enabled
DISABLED: disables the
integrated IDE
Controller.
ENABLED: enables both
Controllers.
Help Item
Onboard IDE Controller (Enabled)
Use this item to enable or disable the onboard IDE interface.
Onboard SATA Controller (Enhanced)
This item allows you to enable or disable the onboard SATA controller.
Onboard Audio Function (Enabled)
Use this item to enable or disable the onboard audio device.
Onboard LAN Function (Enabled)
Use this item to enable or disable the onboard LAN function.
mnlk
: Move
F10: Save ESC: Exit
Enter : Select
+/-/: Value
F9: Load Default Settings
F1: General Help
Share Memory Size (Enabled, 64MB)
This item lets you allocate a portion of the main memory for the onboard VGA
display application.
DVMT Memory (256MB)
When set to Fixed Mode, the graphics driver will reserve a fixed portion of the
syste
m memory as graphics memory, according to system and graphics requirements.
Press <Esc> to return to the main menu setting page.
Memory Remap Feature (Enabled)
This item allows you to remap the overlapped PCI memory above the total physical
memory if you have a 64 bit OS and 8 GB of RAM.
HPET (Enabled)
This item enables or disables HPET (High Precision Event Timer) support.
