5
Introducing the Motherboard
• Intel G41 & ICH7 Express Chipset
North Bridge: Intel G41 South Bridge: ICH7
• LGA775 socket for Intel Core 2 Quad
*
/Intel
®
Core
TM
2 Duo/
Pentium
®
Dual-Core/Celeron
®
Dual-Core/Celeron
®
400 se-
ries processors
• Dual-channel DDR3 memory architecture
• 2 x 240-pin DDR3 DIMM sockets support up to 8 GB
• Supports DDR3 1066/800 DDR3 SDRAM
*
*(Due to the chipset spec, G41T-M7 runs at DDR3 1066/
800 MHz memory speed)
• 1 x PCI Express x16 slot
• 1 x PCI Express x1 slot
• 1 x PCI slot
• Supported by Intel ICH7 Express Chipset
• 2 x Serial ATA 3.0 Gb/s device
• 1 x Ultra DMA100/66 devices
• VIA VT1705 6-Ch High Definition audio CODEC
• RealTek 8103 10/100 Fast Ethernet NIC (Gigabit LAN op-
tional)
• 1 x PS/2 keyboard & PS/2 mouse connector
• 1 x VGA port
• 4 x USB ports
• 1 x RJ45 LAN connector
• 1 x Audio port (Line in, microphone in, line out)
Chipset
Memory
Expansion
Slots
Storage
Audio
Giga LAN
Rear Panel I/O
Internal I/O
Connectors &
Headers
• AMI BIOS with 8Mb SPI ROM
• Supports Plug and Play, STR(S3)/STD(S4), Hardware moni-
tor, Multi Boot, DMI
• Supports ACPI revision 1.0 specification
System BIOS
Form Factor • Micro ATX Size, 225mm x 170mm
CPU
Specifications
• 1 x 24-pin ATX Power Supply connector
• 1 x 4-pin CPU_FAN connector
• 1 x IDE connector
• 2 x USB 2.0 headers
• 1 x CLR_CMOS header
• 1 x Speaker header
• 1 x Front panel audio header
• 1 x Front panel switch/LED header
• 1 x Parallel port header(LPT)
•
• 1 x SPDIF out header
• 1 x Serial port header (COM)
• 1 x Chassis intrusion header
2 x SATA 3Gb/s connectors
