ECS GF8100VM-M5 User Manual

13
Installing the Motherboard
Table A: Unbuffered DIMM Support for Socket AM2+/AM2 CPU
DRAM
Speed
DIMM1
1
DIMM2
1
Timing
Mode
Address Timing
Control Register
Output Driver
Compensation
Control Register
DDR2-400 - Any 1T 002F_2F2Fh X011_1222h
DDR2-400 Any Any 2T 002F_2F2Fh X011_1322h
DDR2-533 - Any 1T 002F_2F2Fh X011_1222h
SRx16 SRx16
SRx16 SRx8
DDR2-533
SRx8 SRx16
002F_2F2Fh X011_1322h
DDR2-533 SRx8 SRx8 2T 0000_2F2Fh X011_1322h
DDR2-533 DRx8 DRx8 2T 0034_2F2Fh X011_1322h
DR x8 SRx16
DDR2-533
SRx16 DRx 8
2T 0038_2F2Fh X011_1322h
DRx8 SRx 8
DDR2-533
SRx8 DRx 8
2T 0037_2F2Fh X011_1322h
DDR2-667 - Any 1T 0020_2020h X011_1222h
SRx16 SRx16
SRx16 SRx8
DDR2-667
SRx8 SRx16
2T 0020_2020h X011_1322h
DDR2-667 SRx8 SRx8 2T 0030_2020h X011_1322h
DDR2-667 DRx8 DRx8 2T 002B_2020h X011_1322h
DR x8 SRx16
DDR2-667
SRx16 DRx 8
2T 002C_2020h X011_1322h
DRx8 SRx 8
DDR2-667
SRx8 DRx 8
2T 002A_2020h X011_1322h
DDR2-800 - Any 2T 0020_2520h X011_3222h
DDR2-800 Any Any 2T 0020_2520h X011_3222h
1. SRx16=Single Rank x16 DIMM
SRx8=Single Rank x8 DIMM
DRx16=Dual Rank x16 DIMM
DRx8=Dual Rank x8 DIMM

ECS GF8100VM-M5 Specifications

General

Number of memory slots	2
Maximum internal memory	16 GB
Processor socket	Socket AM2
Processor manufacturer	AMD
USB 2.0 connectors	4
Power fan connector	Yes
Number of SATA connectors	6
Controller interface type	NVIDIA MCP78V
PS/2 ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	0
Audio chip	VIA VT1708B
Power source type	ATX
Audio output channels	6.1 channels
Motherboard form factor	micro ATX
BIOS type	AMI
Maximum graphics card memory	512 MB
RAID levels	0, 1
