30
Using BIOS
Standard CMOS Setup
This option displays basic information about your system.
Date Tue 07/04/2008
f
Primary IDE Master Not Detected
Primary IDE Slave Not Detected
Help Item
f
CMOS Setup Utility -- Copyright (C) 1985-2005, American Megatrends, Inc.
Time 17:41:06
User [Enter], [TAB]
or [SHIFT-TAB] to
select a field.
Use [+] or [-] to
configure system Date.
Standard CMOS Setup
Date & Time (Not Detected)
The Date and Time items show the current date and time on the computer. If you are
running a Windows OS, these items are automatically updated whenever you make
changes to the Windows Date and Time Properties utility.
IDE BusMaster Enabled
Drive A: 1.44 MB 3
1
/
2
”
: Move
F10: Save ESC: Exit
Enter : Select
+/-/: Value
F9: Load Default settings
F1: General Help
mn
< >
SATA1 Not Detected
SATA 2 Not Detected
SATA 3 Not Detected
SATA 4 Not Detected
f
f
f
f
The item defines the characteristics of any diskette drive attached to the system.
You can connect one diskette drive.
Drive A (1.44 MB 3
1
/
2
”)
IDE BusMaster (Enabled)
Primary IDE Master/Primary IDE Slave (Not Detected)
Use these items to configure devices connected to the Primary IDE channels. To
configure an IDE hard disk drive, choose Auto. If the Auto setting fails to find a hard
disk drive, set it to User, and then fill in the hard disk characteristics (Size, Cyls, etc.)
manually. If you have a CD-ROM drive, select the setting CDROM. If you have an
ATAPI device with removable media (e.g. a ZIP drive or an LS-120), select Floptical.
SATA1~4 (Not Detected)
This item enables or disables the DMA under DOS mode. We recommend you to leave
this item at the default value.
These items display the status of auto detection of sata devices when “Onboard
SATA-IDE” set to “IDE”.
