Integrated Peripherals
This page sets up some parameters for peripheral devices connected to the system.
CMOS Setup Utility - Copyright (C) 1985-2005, American Megatrends, Inc.
Integrated Peripherals
Onboard IDE Controller Enabled
OnChip S-ATA Controller Enabled
SATA Mode select SATA Mode
Onboard AUDIO Function Enabled
Onboard LAN Function Enabled
Onboard LAN Boot ROM Disabled
Serial Port1 Address 3F8/IRQ4
Parallel Port Address 378
Parallel Port Mode ECP
ECP Mode DMA Channel DMA3
Parallel Port IRQ IRQ7
USB Controller Enabled
Legacy USB Support Enabled
Help Item
: Move
F10: Save ESC: Exit
Enter : Select
+/-/: Value
F9: Load Default settings
F1: General Help
mn
< >
SATA Mode Select (SATA Mode)
Use this item to select the mode of the Serial ATA.
OnBoard AUDIO Function (Enabled)
OnBoard LAN Function (Enabled)
OnBoard LAN Boot ROM (Enabled)
Use this item to enable or disable the booting from the onboard LAN or a network
add-in card with a remote boot ROM installed.
Serial Port1 Address ( 3F8/IRQ4)
Use this item to enable or disable the onboard COM1 serial port, and to assign a port
address.
Parallel Port Address (378)
Parallel Port Mode (ECP)
Use this item to enable or disable the onboard Parallel port, and to assign a port
address.
OnBoard IDE Controller (Enabled)
Use this item to enable or disable the onboard IDE interface.
This item allows you to enable or disable the onboard SATA controller.
Use this item to select the parallel port mode. You can select Normal (Standard
Parallel Port), ECP (Extended Capabilities Port), EPP (Enhanced Parallel Port), or
BPP (Bi-Directional Parallel Port).
Use this item to enable or disable the onboard Audio function.
Use this item to assign the DMA Channel under ECP Mode function.
Onboard S-ATA Controller (Enabled)
Use this item to enable or disable the onboard LAN function.
ECP Mode DMA Channel (DMA3)
Note: Due to the limitation of NVIDIA chipset, SATA5~6 support AHCI/RAID mode
only.
